Tripod Turnstile Time Attendance for Construction Site
Production Description ：
LD-T301 three roller gate is easy to integrate IC card, ID Recognition equipment such as cards, QR codes, fingerprints, and face recognition device, which can manage the pedestrian access control effectively and intelligently. It is widely used in commercial complexes, residential quarters, enterprises and institutions, factories, scenic spots, construction sites, transportation hubs, etc. Where the channel realizes intelligent management.
Product Parameters:
| Moduel No. | LD-T311 |
| Size | 1200*230*980mm |
| Material | 304 stainless steel, acrylic |
| Unlocking time | 0.2s |
| Traffic speed | ≤35 persons/min |
| Channel width | ≤550mm |
| Input voltage | 220V, 50HZ |
| Drive voltage | 24V |
| Ambient temperature | : -25~+70 |
| Power | 30W |
| Opening signal input | dry contact |
| The material thickness | 1.2mm |
Highlight :
1.Super compatibility
2.Adopt brushless motor, low wear and tear, stable operation
3.Alarm when people break in.
4.Anti-tailing, fast passing speed.
5.Beautiful, generous and high-end in appearance
Product Functions :
1. With fault self-checking and alarm prompt function, it is convenient for users to maintain and use;
2. A variety of traffic modes can be set.
3. Anti-shock function, the gate is automatically locked when the gate opening signal is not received;
4. Sound and light alarm when there is a illegal break-in and trailing;
5. Infrared anti-pinch function, when the gate is reprocessing, the gate will automatically return to the open state if the infrared detects a person in the passage;
6. The swing arms can be adjusted at the same time (for double swing conditions);
7. It has an automatic reset function. After opening the gate, the swing gate will reset automatically when it is not passing within the specified time, and the waiting time is adjustable (default time is 5S);
8. The unified standard external port can be connected to a variety of access control equipment, and can be remotely controlled and managed through the computer.
9. Support multi-functional system customization and docking.
Economical three-roller gates, mostly used in construction sites , factories and viewpoint, and can be customized for scenic spot ticketing systems, construction site access control systems and other multi-functional systems
CE Certification :
